Description
4 Pole 80A 100mA Time Delay Type A RCD
WCED ATDR480-100
The WCED ATDR480-100 is a 4-pole Time Delay RCD designed for 80A rated current and 100mA earth-leakage sensitivity. Its time-delayed functionality ensures effective discrimination when two RCDs are installed in series, allowing only the upstream RCD to trip during a fault. This feature makes it an essential component for electrical safety in residential, commercial, and industrial systems.
Detailed Features and Functionality
The WCED ATDR480-100 enhances safety by detecting residual currents and ensuring selective tripping in multi-RCD setups. Its Type A classification makes it capable of detecting AC and pulsating DC currents, providing reliable protection across a variety of electrical environments. Moreover, its time-delay feature improves system stability by reducing unnecessary disconnections.
Operating at 230/400V, this RCD supports a rated conditional short-circuit current of 10kA, ensuring robust performance in demanding conditions. Its mechanical durability of 4,000 cycles and electrical durability of 2,000 cycles ensure long-term reliability. The device complies with BS EN 61008-1 standards, meeting strict safety and performance requirements.
This RCD is built for indoor use, with an IP20 rating providing protection against contact and basic dust ingress. It operates efficiently within a temperature range of -25°C to +40°C, maintaining consistent performance across different environments.
Key Features of WCED ATDR480-100
- 4 Pole Design: Provides comprehensive protection for three-phase systems.
- Rated Current: 80A, suitable for medium- to high-load circuits.
- Earth-Leakage Sensitivity: 100mA for reliable fault detection.
- Type A Classification: Detects AC and pulsating DC currents for versatile safety.
- Time-Delayed Functionality: Ensures selective tripping in multi-RCD setups.
- Durable Construction: Withstands 4,000 mechanical cycles and 2,000 electrical cycles.
- Voltage Ratings: Operates at 230/400V with a 10kA conditional short-circuit rating.
- IP20 Protection: Suitable for indoor installations conforming to BS EN 60529.
- Compliance: Certified to BS EN 61008-1 standards.
