Description
4 Pole 25A Normally Closed Modular Contactor
The WCED 4 Pole 25A 4NC Modular Contactor is a versatile and compact device designed for efficient control of electrical systems in residential, commercial, and industrial applications. Its robust build and modular design ensure long-lasting performance and seamless integration into electrical panels and enclosures.
Key Features of 4 Pole 25A Normally Closed Modular Contactor
- 25A Current Rating: Handles moderate load requirements with ease.
- 4 Pole Configuration: Includes 4 normally closed (NC) contacts for comprehensive control.
- Compact Modular Design: Fits seamlessly into consumer units and standard enclosures.
- Silent Operation: Noise-free switching ideal for residential or office environments.
- Rated Voltage: Operational voltage of 230/400V @ 50Hz.
- Durable Protection: Rated IP20, conforming to BS EN 60529 for safety.
- Standards Compliance: Meets BS EN 61095 and BS EN 60947-4-1 standards.
- Wide Operating Range: Functions reliably between -25 °C and +40 °C.
- Secure Mounting: Compatible with 35 mm DIN rails, with a recommended torque of 2.0Nm.
Technical Specifications
- Utilisation Categories: AC-7a (resistive loads) and AC-1 (slightly inductive loads).
- Control Voltage: 230V AC for electromagnetic coil operation.
- Switching Frequency: Supports high switching rates for repeated operations.
- Insulation Voltage: Rated up to 500V.
- Mechanical Durability: Up to 1,000,000 switching cycles.
Applications
- Residential: Automation of lighting, appliances, and heating systems.
- Commercial: Reliable control for office lighting and HVAC systems.
- Industrial: Efficient switching of circuits in manufacturing and production facilities.
How It Works
The WCED 4 Pole 25A 4NC Modular Contactor operates using an electromagnetic coil activated by a 230V control voltage:
- Activation: Energising the coil creates a magnetic field that engages the armature, maintaining normally closed (NC) contacts in their default state.
- Switching: The robust NC contacts efficiently interrupt power flow when de-energized, offering reliable load control.
- Reset: A spring mechanism returns the armature to its default position when the coil is de-energized.
Why Choose This Contactor?
The WCED 4 Pole 25A 4NC Modular Contactor combines reliability, durability, and silent operation, making it a top choice for professionals. With compliance to stringent standards and compatibility with a wide range of systems, it ensures safe and efficient electrical control.
