32A Curve B 30mA A Type RCBO – Compact RCBO, Switched Line & Neutral, 6kA
Robust Protection for High-Use Circuits – Niglon RCBO1-32/30SSAX 32A RCBO
Niglon RCBO1-32/30SSAX
The Niglon RCBO1-32/30SSAX 32A RCBO is a compact RCBO designed to deliver reliable protection for ring mains, socket circuits, and general-purpose power loads. This single-module device combines overcurrent and 30mA residual current protection in a space-saving 18mm-wide housing, making it ideal for consumer units with limited space.
Thanks to its Curve B tripping profile, it is well suited for circuits with resistive or lightly inductive loads. Additionally, the Type A RCD detects both AC and pulsating DC leakage currents—ensuring compliance with the latest 18th Edition standards.
It also features switched line and neutral disconnection for safer fault isolation and improved servicing conditions.
Key Features of the Niglon RCBO1-32/30SSAX 32A RCBO
- Rated Current: 32A – Perfect for ring mains, kitchen sockets, and high-usage circuits
- Curve B Tripping – Activates at 3–5x rated current
- 30mA Type A RCD – Detects AC and pulsating DC residual currents
- Switched Line & Neutral – Safely disconnects both conductors during faults
- Breaking Capacity: 6kA – Suitable for most domestic boards
- Compact RCBO – Only 18mm wide, ideal for space-limited units
- Voltage: 230V AC, 50Hz
- Cable Capacity: 25mm² (line in), 10mm² (line/neutral out)
- Standards: BS EN 61009-1, BS7671:2018 (18th Edition)
Applications
- 32A ring mains for socket outlets
- Kitchen or utility room power circuits
- Office and workshop outlets
- Upgrades to 18th Edition consumer units
Why Choose the Niglon RCBO1-32/30SSAX
The Niglon RCBO1-32/30SSAX 32A RCBO offers dependable performance and compact design, making it ideal for everyday power circuits. With Type A earth fault detection, switched line and neutral isolation, and Curve B tripping, it supports full 18th Edition compliance in domestic and commercial settings.
Summary
The Niglon RCBO1-32/30SSAX RCBO is a Curve B, Type A compact RCBO offering overcurrent and 30mA RCD protection. It includes switched line and neutral disconnection, a 6kA breaking capacity, and a slim 18mm profile—perfect for ring circuits and socket protection.
