10A Curve B 30mA A Type RCBO – Mini RCBO, Switched Line & Neutral, 6kA
Safe and Compact Protection for Small Power Circuits – Niglon RCBO1-10/30SSAX 10A RCBO
Niglon RCBO1-10/30SSAX
The Niglon RCBO1-10/30SSAX 10A RCBO offers dependable protection for lighting and small power circuits. It combines overcurrent and 30mA residual current protection in a single, compact module. Thanks to its Curve B tripping profile, this mini RCBO is ideal for resistive loads like socket circuits and lighting.
Importantly, this device features a Type A RCD, which detects both AC and pulsating DC earth leakage faults. This makes it suitable for circuits connected to modern electronic devices. Additionally, the switched line and neutral design ensures full disconnection during faults, improving safety and compliance.
As a result, this RCBO is an excellent choice for installations where space is limited and high safety standards are required.
Key Features of the Niglon RCBO1-10/30SSAX 10A RCBO
- Current Rating: 10A – For lighting, small socket outlets, and appliances
- Tripping Curve: Curve B – Trips between 3–5x the rated current
- RCD Type: Type A – Detects AC and pulsating DC residual currents
- Residual Current Sensitivity: 30mA – For personal protection
- Poles: 1P+N – Provides switched protection to both line and neutral
- Switched Line & Neutral – Allows safe isolation for testing and servicing
- Breaking Capacity: 6kA – Suitable for domestic distribution boards
- Module Width: 18mm – Slim mini RCBO for compact boards
- Voltage: 230V AC, 50Hz
- Cable Capacity: 25mm² (line in), 10mm² (line/neutral out)
- Standards: BS EN 61009-1, BS7671:2018
Applications
- Domestic socket or lighting circuits
- Small power appliances and accessories
- Garden rooms, garages, or outbuildings
- New installations or 18th Edition upgrades
Why Choose the Niglon RCBO1-10/30SSAX?
The Niglon RCBO1-10/30SSAX 10A RCBO offers high-performance circuit protection in a compact format, making it ideal for small power circuits. It supports 18th Edition compliance, delivers switched line and neutral isolation, and provides modern earth fault detection with Type A RCD sensitivity.
Summary
The Niglon RCBO1-10/30SSAX is a Curve B, Type A, 30mA mini RCBO offering protection for small power and lighting circuits. It features switched line and neutral disconnection, 6kA breaking capacity, and a compact 18mm width for space-saving boards.
