16A Curve B 30mA A Type RCBO – Mini RCBO, Switched Line & Neutral, 6kA
Enhanced Safety for General Purpose Circuits – Niglon RCBO1-16/30SSAX 16A RCBO
Niglon RCBO1-16/30SSAX
The Niglon RCBO1-16/30SSAX offers dependable protection for power and lighting circuits, especially where resistive or mixed loads are present. It integrates overcurrent and residual current protection into a compact 18mm-wide mini RCBO, helping you save space inside the consumer unit.
With a Curve B tripping profile, it’s ideal for general-purpose applications such as ring mains, lighting banks, and small fixed appliances. Its Type A RCD feature ensures it detects both AC and pulsating DC earth leakage, providing superior protection in homes and small commercial settings.
Furthermore, the inclusion of switched line and neutral improves electrical safety by isolating both conductors during faults or servicing.
Key Features of the Niglon RCBO1-16/30SSAX 16A RCBO
- Current Rating: 16A – Suitable for ring circuits, lighting, and small appliances
- Tripping Curve: Curve B – Trips at 3 to 5 times rated current
- 30mA Type A RCD – Detects AC and pulsating DC leakage faults
- Switched Line & Neutral – Safer isolation during faults or maintenance
- Breaking Capacity: 6kA – Suitable for domestic and light commercial boards
- Compact Design – Only 18mm wide, ideal for consumer units with limited space
- Voltage: 230V AC, 50Hz
- Cable Capacity: 25mm² (line in), 10mm² (line/neutral out)
- Compliance: BS EN 61009-1, BS7671:2018 (18th Edition)
Applications
- Ring circuits in homes or flats
- Lighting circuits with mixed loads
- Small electric heaters or fixed appliances
- Consumer unit upgrades and rewires
Why Choose the Niglon RCBO1-16/30SSAX 16A RCBO?
The Niglon RCBO1-16/30SSAX 16A RCBO provides a compact and compliant safety solution for a wide range of circuits. Its Curve B profile supports sensitive fault detection, while Type A protection ensures it responds to modern earth leakage faults. In addition, its 18mm mini RCBO format helps maximise space within crowded boards.
Summary
The Niglon RCBO1-16/30SSAX is a compact, 18mm-wide Type A RCBO with Curve B tripping and 30mA sensitivity. It offers switched line and neutral isolation and 6kA protection—ideal for lighting and small power circuits.
