Description
10A Bi-Directional AFDD RCBO
Niglon AFDD6B1-10A2
Protect your electrical circuits with the Niglon AFDD6B1-10A2, a compact and reliable Bi-Directional Arc Fault Detection Device (AFDD) combined with a Type A RCBO. This device is ideal for residential and commercial applications, detecting both series and parallel arc faults to help prevent electrical fires.
AFDDs continuously monitor circuit patterns and detect irregularities caused by damaged cables, loose terminals, or worn insulation. When a potentially dangerous arc fault is identified, the device immediately interrupts the power, reducing the risk of fire or equipment damage.
The Niglon AFDD6B1-10A2 fully complies with BS 7671 (18th Edition), which recommends the use of AFDDs in locations such as sleeping accommodation and buildings at greater risk of fire. Its compact 18mm width allows easy installation in space-restricted consumer units.
This Bi-Directional AFDD RCBO offers additional protection by combining overload, short-circuit, and residual current monitoring into a single device. It works regardless of the line/load orientation, making installation quicker and more flexible for electricians.
Key Features of the Niglon AFDD6B1-10A2 Bi-Directional AFDD RCBO
- Rated Current: 10A
- Bi-Directional Arc Fault Detection
- Type A RCD with 30mA sensitivity
- 1P+N, 230V, Curve B tripping
- Breaking Capacity: 6kA
- Compact 18mm width
- Complies with BS EN 61009-1 and BS EN 62606
- Detects both series and parallel arc faults
About the Brand
Niglon is a respected UK-based brand offering a wide range of electrical accessories. Their circuit protection products meet strict standards, making them a trusted choice for professional electricians and installers across the country.
Why Buy From Electrical4Less?
We offer fast delivery, competitive prices, and excellent service. Every product is carefully selected to ensure compliance and reliability, so you can shop with confidence at Electrical4Less.
Summary
The Niglon AFDD6B1-10A2 Bi-Directional AFDD RCBO is a safe and efficient circuit protection device that meets the latest wiring regulations.
It offers complete protection from arc faults, overloads, and residual currents, making it ideal for domestic and commercial use.
