Description
EV Connection Centre with O-PEN 63A TPN and Type 2 SPD
matt:e ARD-1-63-TP-SPD
Simplifying EV Charger Installations with Advanced Protection
Fast, Compliant, and Cost-Effective EV Charging Solutions
The matt:e ARD-1-63-TP-SPD Connection Centre offers a safe, regulation-compliant, and easy-to-install solution for EV charge points. Featuring built-in O-PEN® technology, it eliminates the need for earth electrodes, reducing both installation costs and disruption.
Equipped with a 5-pole automatic reset isolator and Type 2 SPD, this connection centre protects EV chargers against voltage surges and power supply issues. Designed for 63A TPN loads, it ensures a reliable and efficient electrical connection.
Key Features and Benefits
✅ O-PEN® Technology for PME Compliance
- No earth electrodes required, cutting installation costs and time.
- Prevents accidental damage to buried services, reducing risks.
✅ Easy Installation with Wire-In, Wire-Out Design
- Top and bottom cable entry allows for flexible wiring.
- Pre-configured system simplifies EV charger connections.
✅ Enhanced Electrical Protection
- Built-in Type 2 SPD shields against surge damage.
- 5-pole auto-reset isolator restores power without manual intervention.
✅ Durable Construction for Long-Term Reliability
- Mild steel IP4X enclosure ensures protection and durability.
- 1-year parts warranty for peace of mind.
✅ Fully Compliant with EV Charging Regulations
- Meets BS 7671:2018 Amendment 2 (2022) Regulation 722.411.4.1.(iii).
Technical Specifications
- Input Voltage: 400V 50Hz
- Maximum Load: 63A TPN
- Cable Entry: Top & Bottom
- Terminal Capacity: 25mm²
- Enclosure Material: Mild Steel Powder-Coated
- Ingress Protection: IP4X
- Dimensions (H x W x D): 380mm x 300mm x 120mm
- Weight: Approx. 7kg
- Warranty: 1 Year
Ideal Applications
- EV Charging Points – Simplifies charger connections while ensuring compliance.
- Commercial & Industrial Electrical Setups – Provides a robust and regulation-ready solution.
- Future-Proof Installations – Reduces groundwork disruptions while offering long-term safety.
Why Choose the matt:e ARD-1-63-TP-SPD?
This unit is engineered for hassle-free, regulation-compliant EV installations. With built-in O-PEN®, a Type 2 SPD, and an auto-reset isolator, it ensures long-term reliability, surge protection, and cost-efficient installation.
