Description
Maximum-Current Protection for High-Load PV Strings
Live Electrical PV-FU32A10 32A 20kA 10×38 1000V DC Photovoltaic Fuse
The Live Electrical 32A 1000VDC photovoltaic fuse for solar systems is built for the most demanding DC circuit protection tasks in PV installations. Designed in a compact 10x38mm format and featuring a 20kA breaking capacity, this gPV-class fuse is ideal for high-load strings in both commercial and residential solar applications. It ensures safe disconnection under fault conditions and is fully compatible with standard 10×38 fuse holders.
Key Features – 32A 10×38 1000V DC Photovoltaic Fuse
- Rated Current: 32A
- Rated Voltage: 1000VDC
- Breaking Capacity: 20kA
- Fuse Size: 10x38mm
- Function Class: gPV
- Application: High-load PV string protection
- Brand: Live Electrical – trusted for quality and performance
Technical Overview
The PV-FU32A10 is the highest-rated current fuse in the range, delivering safe and reliable interruption in high-current DC circuits. It fits all Live Electrical 10×38 holders including models PV32-1085 and PV32-1038X, providing seamless integration into your solar fuse setup.
- Product Code: PV-FU32A10
- Standards: IEC/EN60269-6 compliant
- Body: High-ceramic housing with silver-plated contacts
- Use Case: Incoming PV string fuse protection
- Compatibility: Fits 10×38 fuse holders for solar DC systems
What’s Included
- 1 x Live Electrical PV-FU32A10 Photovoltaic Fuse (32A, gPV, 1000VDC)
Why Choose This Product?
Perfect for high-load solar DC applications, this 32A gPV fuse ensures safe and controlled disconnection under overcurrent or fault conditions. It’s an excellent solution for PV fuse protection in large-scale installations where reliability and current rating matter most.
Guarantee & Compliance
This photovoltaic fuse complies with IEC/EN60269-6 standards and is suitable for integration into a wide range of solar power systems. Manufactured to high specifications by Live Electrical.
Summary – 32A 10×38 1000V DC Photovoltaic Fuse
The Live Electrical 32A 1000VDC photovoltaic fuse delivers gPV protection for high-load PV strings. Compact 10x38mm form with 20kA breaking capacity—ideal for demanding solar DC circuits.
