20A High-Voltage Solar Fuse for 1500VDC PV Arrays
1500V DC Photovoltaic Fuse 20A 20kA 10×85 – Live Electrical PV-FU20A15
The Live Electrical 20A 10×85 1500V DC Photovoltaic Fuse for solar installations is engineered for reliable protection in high-voltage PV systems. Featuring a gPV classification, 10x85mm body, and a robust 20kA breaking capacity, this fuse is ideal for isolating faults in 1500V DC solar circuits. Suitable for both commercial and industrial PV arrays, it pairs seamlessly with 1500V-compatible fuse holders.
Key Features – 20A 10×85 1500V DC Photovoltaic Fuse
- Rated Current: 20A
- Rated Voltage: 1500VDC
- Size: 10x85mm
- Breaking Capacity: 20kA
- Function Class: gPV
- Application: High-voltage DC PV string protection
- Brand: Live Electrical – solar protection specialists
Technical Overview
This gPV-class fuse provides dependable overcurrent protection in 1500V PV systems. Its extended 10x85mm design suits large installations and ensures safe fault disconnection for long-duration current flow and high short-circuit conditions.
- Product Code: PV-FU20A15
- Standards: Complies with IEC/EN60269-6
- Body Type: Durable ceramic with silver-plated terminals
- Compatibility: Works with 10x85mm fuse holders rated for 1500VDC
- Application Use: PV string and array protection
What’s Included
- 1 x Live Electrical PV-FU20A15 Photovoltaic Fuse (20A, gPV, 1500VDC)
Why Choose This Product?
Designed for use in demanding environments, this 20A 1500V solar fuse delivers safe, high-capacity protection where failure is not an option. Ideal for engineers and installers seeking 1500VDC fuse protection for solar PV arrays with dependable performance.
Guarantee & Compliance
This fuse is manufactured to IEC/EN60269-6 specifications and approved for use in high-voltage photovoltaic circuits. Live Electrical ensures strict quality control and reliability.
Summary – 20A 10×85 1500V DC Photovoltaic Fuse
The Live Electrical 20A 1500VDC photovoltaic fuse in 10x85mm format offers gPV-class protection with 20kA breaking capacity. A perfect fit for modern high-voltage PV solar systems.
