Live Electrical Double Pole Type A RCBO – Curve B – 6A

Description

Live Electrical Double Pole Type A 6A Curve B RCBOs are specifically designed for individual EV chargers, ensuring protection regardless of the vehicle model and make being charged. They detect and respond to both AC currents and pulsating DC components, providing comprehensive safety.

Key Features:

• Rated Current (In): Available in 6A, 10A, 16A, 20A, 25A, 32A, and 40A.
• Rated Voltage (Un): 230V AC.
• Breaking Capacity (Icn): 10kA.
• Rated Residual Current: 30mA.
• Tripping Characteristics: Curve B
• Electrical Endurance: 4,000 cycles.
• Mechanical Endurance: 10,000 cycles.
• Compliance: Meets BS EN 61009-1 standards.

Ensure the safety and efficiency of your EV charging system with the Double Pole Type A 6A Curve B RCBO.

Benefits:

• Enhanced Safety: Detects and responds to AC and pulsating DC currents, ensuring protection for EV chargers.
• Durable Performance: Offers high electrical and mechanical endurance for long-lasting reliability.
• Versatile Applications: Ideal for individual EV chargers and other electrical installations.
