⚡ Compact & Reliable Circuit Protection – Hager MTN116 MCB 6kA B-16
High Performance Type B MCB for Single Phase Installations
The Hager MCB 6kA B-16 is a single pole Type B miniature circuit breaker rated at 16A with a short-circuit breaking capacity of 6kA. It provides reliable protection against overloads and short circuits in domestic and commercial settings.
This Hager MCB features a screw terminal connection, B curve tripping characteristic, and supports 360° mounting. Designed to meet IEC 60898-1 standards, it is suitable for environments with high humidity and a pollution degree of 2, operating between -25°C and 70°C.
Included
- 1 × Hager MTN116 MCB 6kA B-16 Type B MCB (16A, 1P, 6kA)
Key Features
- Current Rating: 16A
- Tripping Curve: Type B
- Breaking Capacity: 6kA (IEC 60898-1)
- 1 module wide (17.5mm)
- Voltage: 230–400V AC
- Rated insulation voltage: 500V
- Impulse withstand voltage: 4,000V
- Screw terminal with 2.8 Nm tightening torque
- Supports 1–35 mm² rigid / 1–25 mm² flexible conductors
- Ingress Protection: IP20
- Energy limitation class: 3
- Ambient temperature: -25°C to +70°C
- Mounting: DIN rail with 360° flexibility
✅ Why Choose This MCB?
- Trusted Hager quality with robust construction
- Fast disconnection under fault conditions
- Reliable protection in residential and light commercial boards
- Compatible with aligned modular terminal systems
Summary
The Hager MTN116 MCB 6kA B-16 provides compact, reliable, and standards-compliant protection for 230–400V single phase systems. With a 6kA breaking capacity, full IEC conformity, and durable screw terminals, it’s an ideal MCB choice for modern installs.
