Description
1 Phase kWh Meter Direct 80A 2M MBUS MID
Hager ECM180D
The Hager ECM180D is a high-capacity single-phase kWh meter with MBUS communication, designed for direct 80A measurement. This 2M MID-certified meter is perfect for residential, commercial, and industrial energy monitoring. With its robust design, advanced features, and retro-illuminated display, it ensures accurate energy measurement and seamless integration into modern energy management systems.
Key Features of Hager ECM180D 1 Phase kWh Meter
- MBUS Communication: Allows easy integration into energy monitoring systems for real-time data tracking.
- Direct 80A Measurement: Handles higher loads, making it suitable for heavy-duty applications.
- Compact 2M Design: Fits into space-constrained installations with a width of 36mm.
- Retro-Illuminated Display: Ensures clear visibility of energy usage data in all lighting conditions.
- Single-Phase Counter: Designed for 1P+N systems with precise energy tracking.
- MID Certified: Compliant with accuracy standards for billing and energy management.
- DIN Rail Mounting: Simplifies installation with secure and quick setup.
- Energy Efficient: Consumes only 2VA power with a total power loss of 1W under nominal current.
- Wide Operating Temperature: Suitable for diverse environments with a range of -25°C to 55°C.
Technical Specifications
Architecture:
- Number of Poles: 2P (1P+N)
- Fixing Mode: DIN rail type O (symmetrical)
Electrical Features:
- Rated Operational Voltage (Ue): 92-276V AC
- Frequency: 50Hz
- Max Operating Voltage: 300V
- Rated Impulse Withstand Voltage: 6kV
Physical Dimensions:
- Depth: 60mm
- Height: 92mm
- Width: 36mm
Power Consumption:
- Power Consumed: 2VA
- Total Power Loss: 1W
Measurement:
- Type: Electronic Measuring Instrument
Display and Counter:
- Display: Retro-Illuminated Display
- Counter Type: Single-Phase
Standards and Protection:
- Protection Index: IP20
- European Directive WEEE: Concerned
Operating Conditions:
- Operating Temperature: -25°C to 55°C
Installation:
- Tightening Torque: 2 Nm
Applications
The Hager ECM180D is ideal for:
- Residential: Monitor energy consumption for high-demand appliances or homes.
- Commercial: Track power usage in offices, retail outlets, and facilities with higher loads.
- Industrial: Measure energy in warehouses, manufacturing plants, and heavy-duty environments.
Why Choose the Hager ECM180D?
The Hager ECM180D stands out with its 80A capacity, MBUS communication, and robust build quality. It is perfect for applications requiring precise energy monitoring for higher loads. Its retro-illuminated display ensures easy readability, and the MID certification guarantees compliance with international accuracy standards.
