16A 2P+E 3 Pin Plug – 100–130V (110V Class) – Straight Connector
🟡 Gewiss GW62001H 16A 110V Plug – IP44/IP54 – Screw Wiring – Yellow – IEC 309 HP Range
The Gewiss GW62001H is a 16A straight connector plug (2P+E), ideal for low-voltage industrial or commercial applications. Designed for 100–130V systems—commonly referred to as 110V—this compact 3 pin plug ensures reliable and durable power connections in mobile setups or site installations.
Built from halogen-free materials, this plug meets IEC 60309 standards, offering IP44/IP54 protection against dust and splashes and IK09 mechanical resistance for high durability. With nickel-plated contacts, it resists corrosion and maintains consistent conductivity, even in demanding environments.
Moreover, its screw terminal wiring and integrated cable clamp allow fast, secure installation, making it a practical choice for professionals in the field.
⚙️ Key Features of the Gewiss GW62001H 16A 110V Plug
- Rated Current: 16A
- Poles: 2P+E (3 pin plug)
- Rated Voltage: 100–130V (suitable for 110V systems)
- Frequency: 50/60 Hz
- Connector Type: Straight plug
- Ingress Protection: IP44/IP54
- Mechanical Resistance: IK09
- Color: Yellow
- Hour Reference: 4H
- Wiring Type: Screw terminals
- Cable Capacity:
- Flexible: 1–2.5 mm²
- Rigid: 1.5–4 mm²
- Clamp Range: 7.5–13.8 mm
- Material: Halogen-free (EN 60754-2 compliant)
- Glow Wire Test: 850°C (active), 650°C (passive)
- Thermo-pressure with Ball: 125°C (active), 80°C (passive)
- Operating Temperature: -25°C to +55°C
- Insulation Resistance: > 10 MΩ
- Permissible Overload: 22A
- Breaking Capacity at 1.1 Un: 20A
- Operational Lifespan: Over 5000 operations
✅ Why Choose Gewiss GW62001H 16A 110V Plug?
If you’re working with 110V tools or portable equipment, the Gewiss GW62001H provides a secure and standards-compliant solution. It’s compact, rugged, and simple to wire—ideal for temporary site setups, mobile machinery, or any low-voltage power application.
In addition, its yellow color and 4H keying prevent mismatched connections, improving operational safety.
🌐 Ideal Use Cases
- Construction sites
- Temporary electrical panels
- Mobile lighting setups
- Portable generators or transformers
- Commercial 110V systems
❓ Frequently Asked Questions (FAQs)
- Q: Is this a 110V plug?
A: Yes, it’s rated for 100–130V and commonly used in 110V power systems. - Q: Is it a 3 pin plug?
A: Yes, it has a 2P+E configuration, making it a standard 3 pin design. - Q: What kind of cables can be used?
A: It supports 1–2.5 mm² flexible and 1.5–4 mm² rigid cables, with a clamp range of 7.5–13.8 mm. - Q: Can it be used outdoors?
A: It’s suitable for protected or semi-outdoor use, thanks to its IP44/IP54 rating. - Q: How many cycles is it rated for?
A: It’s rated for over 5000 connections/disconnections.
Summary of the Gewiss GW62001H 16A 110V Plug
The Gewiss GW62001H is a 16A 2P+E straight connector plug for 100–130V (110V) applications. It features IP44/IP54 protection, screw terminals, and a halogen-free body for safe, efficient, and standards-compliant power delivery. This compact 3 pin plug is ideal for portable or site-based setups, offering fast wiring, strong cable grip, and reliable low-voltage connection performance.
