Description
16A 2P+E 3 Pin Plug – 100–130V (110V Compatible) – Straight Industrial Plug
🟡 Gewiss GW60001H 16A 3 Pin 110V Plug – IP44/IP54 – Screw Wiring – Yellow – IEC 309 HP Range
The Gewiss GW60001H is a 16A 2P+E straight plug designed for 110V (100–130V) single-phase systems, commonly used on UK construction sites and in mobile power setups. Its yellow casing and 4H hour positioning provide quick voltage identification, ensuring safe and standardised connections.
This plug is part of the IEC 309 HP range, complying with IEC 60309-1 and IEC 60309-2 standards. Built from halogen-free materials, it enhances fire safety, while IP44/IP54 ingress protection and IK09 mechanical resistance deliver excellent durability on-site.
The nickel-plated contacts help protect against corrosion, and the screw terminals allow for a fast, secure fit for both flexible and rigid cables. Thanks to its compact straight design, it’s ideal for portable and temporary power solutions.
⚙️ Key Features of the Gewiss GW60001H 16A 3 Pin 110V Plug
- Rated Current: 16A
- Poles: 2P+E (3 pin plug)
- Rated Voltage: 100–130V (ideal for 110V systems)
- Frequency: 50/60 Hz
- Plug Type: Straight industrial plug
- Ingress Protection: IP44/IP54 – splash and dust resistant
- Mechanical Resistance: IK09
- Colour: Yellow
- Hour Reference: 4H
- Wiring Method: Screw terminals
- Cable Compatibility:
- Flexible: 1–2.5 mm²
- Rigid: 1.5–4 mm²
- Clamp Range: 7.5–13.8 mm
- Material: Halogen-free (EN 60754-2 compliant)
- Glow Wire Test: 850°C (active), 650°C (passive)
- Thermo-pressure Resistance: 125°C (active), 80°C (passive)
- Operating Temperature: -25°C to +55°C
- Insulation Resistance: > 10 MΩ
- Breaking Capacity @1.1 Un: 20A
- Permissible Overload: 22A
- Durability: Over 5000 connection cycles
✅ Why Choose Gewiss GW60001H 16A 3 Pin 110V Plug?
If you need a dependable plug for 110V tools or temporary site electrics, the Gewiss GW60001H delivers. It is built for rugged environments, offering quick installation, robust mechanical protection, and safe single-phase operation—all in a compact, professional-grade body.
🌐 Suitable Applications
- 110V construction site equipment
- Temporary lighting systems
- Mobile generators
- Event power setups
- Industrial portable tools
❓ Frequently Asked Questions (FAQs)
- Q: Is this compatible with UK 110V systems?
A: Yes, it’s rated for 100–130V and is widely used on British 110V systems. - Q: What plug type is it?
A: It’s a 2P+E (3 pin) straight plug for single-phase power. - Q: Can it be used outdoors?
A: Yes, in covered or semi-protected areas. It offers IP44/IP54 splash and dust protection. - Q: What type of wiring does it support?
A: Screw terminals, suitable for both flexible and rigid cable types. - Q: Is it durable for regular use?
A: Yes, it’s rated for over 5000 operations and built to withstand impact and environmental stress.
Summary of the Gewiss GW60001H 16A 3 Pin 110V Plug
The Gewiss GW60001H is a 16A 2P+E straight plug for 100–130V (110V) systems, ideal for UK construction and event setups. It features IP44/IP54 protection, a halogen-free body, corrosion-resistant contacts, and secure screw wiring. This 3 pin plug ensures safe, durable, and easy-to-install power connections for temporary and portable applications.
