Description
PowerSure 4 Core 2.5mm² NYY-J Cable – 100m
Doncaster Cables NYY4C2.5/100
High-Quality, UV-Stabilised Cable for Fixed Wiring
The Doncaster Cables PowerSure NYY-J Cable offers reliable performance for power and control in fixed wiring installations. Built to BS EN 60502-1 standards, this cable is suitable for both indoor and outdoor applications. Its UV-stabilised black PVC sheath provides long-lasting durability, even in direct sunlight or harsh environments.
Key Features of PowerSure 4 Core 2.5mm² NYY-J Cable
- Conductor: Plain annealed copper, compliant with BS EN 60228.
- Insulation: Premium PVC insulation for long-term reliability.
- Outer Sheath: UV-stabilised black PVC sheath for enhanced outdoor durability.
- Voltage Rating: 600/1000V, ideal for a wide range of applications.
- Operating Temperatures:
- Minimum: -15°C.
- Maximum: 70°C.
- Bending Radius: Minimum 12 times the cable’s outer diameter for safe installation.
- Core Colours:
- 2 Core: Brown, Blue.
- 3 Core: Brown, Blue, Green/Yellow.
- 4 Core: Brown, Green/Yellow, Black, Grey.
- 5 Core: Brown, Blue, Green/Yellow, Black, Grey.
- Current Ratings: Refer to tables 4D2A and 4D2B in the BS7671 IET Wiring Regulations.
Product Details
NYY4C2.5 (4 Core, 2.5mm²)
- Nominal Insulation Thickness: 0.8mm.
- Nominal Sheath Thickness: 1.8mm.
- Approximate Overall Diameter: 12.9mm.
- Conductor Class: Class 1 (solid).
Additional configurations and sizes are available upon request. Contact us for more information about the NYY-J range.
Important Note:
This chart and data are for guidance purposes only. Always consider the actual dimensions of the cables and glands before making a final selection. Manufacturing tolerances as per BS6121: Part 1: 1989 should be taken into account to ensure the correct fit and functionality.
Why Choose Doncaster Cables?
Doncaster Cables is renowned for producing the highest quality cables, trusted by professionals for their durability and compliance with industry standards.
Electrical4Less is an authorised distributor of Doncaster Cables, providing a wide selection of PowerSure products to meet your project requirements.
Why Choose the PowerSure NYY-J Cable?
- Durable Construction: UV-stabilised sheath ensures long-lasting performance in outdoor environments.
- Versatile Applications: Suitable for fixed wiring installations with minimal mechanical stress.
- Compliance: Fully certified to BS EN 60502-1 and BS7671 standards for safe and effective use.
FAQs
- Q: Is this cable suitable for outdoor use?
A: Yes, the UV-stabilised black sheath provides excellent protection for outdoor conditions, including direct sunlight. - Q: What is the minimum bending radius for this cable?
A: The cable requires a bending radius of at least 12 times its overall diameter.
