Description
Y4 Solar Branch Connector Set
Deligo DSY4 – Reliable 4mm Solar Power Connectivity
The Deligo Y4 Solar Branch Connector Set (SKU: DSY4) is designed for high-efficiency solar power systems, ensuring secure, stable, and durable connections in photovoltaic installations. Engineered for optimal performance, this connector set is ideal for both residential and commercial solar setups, meeting stringent international safety standards.
Key Features of the Deligo Y4 Solar Branch Connector Set
- Connector System: 4mm for universal compatibility with standard solar cables
- High Voltage Rating: 1000V DC (IEC) for robust energy transmission
- Durable Current Handling: Supports up to 30A for reliable power flow
- Superior Protection: IP67-rated when connected, ensuring dust-tight and water-resistant performance
- Wide Temperature Range: Operates efficiently from -40°C to +90°C (IEC) and up to +105°C in extreme conditions
- Snap-in Locking System: Secure, tool-free connection with quick-release capability
Technical Specifications
- SKU: DSY4
- Rated Voltage: 1000V DC (IEC)
- Rated Current: 30A
- Test Voltage: 6kV (50Hz, 1 min)
- Ambient Temperature Range: -40°C to +90°C (IEC) / -40°C to +75°C (UL)
- Upper Limiting Temperature: +105°C (IEC)
- Degree of Protection: IP67 (connected), IP2X (unconnected)
- Contact Resistance: 0.5mΩ
- Safety Class: II
- Contact Material: Copper alloy, tin-plated for enhanced conductivity
- Insulation Material: High-quality PC/PA for durability
- Locking System: Secure snap-in mechanism
- Flame Class: UL-94-V0 for superior flame resistance
- Salt Mist Spray Test: Degree of severity 5 (IEC 6068-2-52)
Why Choose the Deligo Y4 Solar Branch Connector Set?
- Optimised for Solar Systems: Ensures maximum energy efficiency and minimal power loss
- Weather-Resistant: IP67 protection for harsh outdoor environments
- Long-Lasting Durability: Resistant to UV rays, temperature fluctuations, and corrosion
- Easy Installation: Quick snap-in locking system for hassle-free setup
- Meets International Standards: IEC and UL certified for safety and performance
Ideal Applications
- Residential and commercial solar panel installations
- Photovoltaic systems in off-grid and grid-tied setups
- Renewable energy projects requiring high-voltage connectors
Ensure secure and efficient solar connections with the Deligo Y4 Solar Branch Connector Set—engineered for performance, safety, and long-term reliability.
