Fusebox Consumer Unit

Buying Guide for FuseBox Consumer Units

FuseBox is a trusted UK brand known for producing high-quality consumer units that provide excellent protection and reliability for electrical installations. If you’re in the market for a FuseBox consumer unit, this guide will help you understand what to look for and how to choose the best one for your needs.

Why Choose FuseBox Consumer Units?

FuseBox offers a wide range of consumer units that cater to different installation needs, whether for residential or small commercial spaces. Key advantages include:

  • Quality Build: Metal enclosures meet UK 18th Edition Wiring Regulations.
  • RCBO Options: Individual circuit protection for enhanced safety.
  • User-Friendly: Easy to install and maintain.
  • Competitive Pricing: Excellent value without compromising safety.
  • Future-Proofing: Units with additional ways for future expansion.

Key Considerations When Buying a FuseBox Consumer Unit

1. Number of Ways (Circuits)

The number of ways refers to the available spaces for circuit breakers (MCBs or RCBOs). FuseBox offers units with varying ways, typically:

  • 6 to 10 Ways: Ideal for smaller homes or installations with fewer circuits.
  • 14 to 20 Ways: Suitable for medium to large homes.
  • 20 Ways+: Designed for larger installations or homes with high circuit demands.

Tip: It’s advisable to choose a unit with a few more ways than you currently need, leaving room for future expansion.

2. RCBO or Dual RCD Protection

FuseBox units come with different configurations based on the type of protection you need:

  • RCBO Protection: FuseBox RCBO consumer units offer individual circuit protection. This means each circuit has its own protection for overcurrent and earth leakage, minimizing the risk of tripping multiple circuits simultaneously.
  • Dual RCD Protection: These units divide the circuits into two groups, each protected by a Residual Current Device (RCD). This is a cost-effective option but can result in multiple circuits being tripped in the event of a fault on one circuit.

RCBO units are generally preferred for their higher level of safety, but Dual RCD units can still provide excellent protection at a lower cost.

3. Surge Protection

Some FuseBox consumer units come with built-in Surge Protection Devices (SPDs), which are important for protecting your electrical system from voltage spikes caused by lightning or power surges.

  • Surge Protection with Type 2 SPD: Recommended for homes with sensitive electronics like TVs, computers, and smart appliances. You can either choose a unit with pre-installed SPDs or add them separately if needed.

4. Build Material

All FuseBox consumer units are made with steel enclosures, which comply with the UK’s 18th Edition Wiring Regulations that require consumer units in domestic installations to be non-combustible. This ensures better fire safety and durability.

5. Ease of Installation and Maintenance

FuseBox units are designed with electricians in mind, offering features that make installation quick and easy:

  • Ample Wiring Space: FuseBox units have spacious enclosures for easy wiring.
  • Removable Pan Assembly: The pan assembly (which holds the circuit breakers) can be easily removed to make installation simpler.
  • Clear Labelling and Indicators: Each unit provides space for labeling circuits, helping to identify and manage circuits after installation.
  • Cable Entry Points: Well-placed entry points for cables, ensuring a clean and safe setup.

Here’s a breakdown of some of the most popular FuseBox consumer units, each designed for different installation requirements:

1. FuseBox F2010MX 10 Way RCBO Consumer Unit

  • Best for Small to Medium Homes
  • Includes 10 useable ways
  • Supplied with 100A main switch and offers RCBO protection.
  • Compatible with Surge Protection Devices (SPD).
  • Compact design with ample wiring space.

2. FuseBox F2014MX 14 Way RCBO Consumer Unit

  • Best for Larger Homes
  • 14 usable ways making it suitable for properties with a higher number of circuits.
  • Comes pre-fitted with a 100A main switch.
  • Excellent for installations where individual circuit protection is a priority.
  • Easy to install with well-thought-out cable management.

3. FuseBox F2006MX Way Consumer Unit with SPD

  • Best for Small Homes and Apartments
  • 6 ways, perfect for installations with a few circuits.
  • Built-in surge protection to safeguard sensitive electronics.
  • Suitable for garages, workshops, or extensions with limited circuits.

Accessories for FuseBox Consumer Units

  • RCBOs: FuseBox RCBOs come in various amperages (e.g., 6A, 32A), providing protection for specific circuits like lighting or sockets.
  • Surge Protection Devices: Can be added to any FuseBox unit that doesn’t already include SPD.
  • Busbars: Ensure that power is distributed evenly to all circuit breakers within the consumer unit.

Installation and Safety

Always ensure that a qualified electrician installs your consumer unit. FuseBox units are designed for professional installation and must comply with UK regulations, such as BS 7671 (18th Edition Wiring Regulations). After installation, the unit should be tested and certified by the installer.

Conclusion

FuseBox consumer units offer excellent value, robust safety features, and flexibility for a wide range of installations. Whether you’re looking for full RCBO protection, dual RCD units, or surge protection, FuseBox provides reliable and compliant solutions that can be tailored to your specific electrical system.

When purchasing, consider the number of circuits, the type of protection, and any future expansion needs. For larger installations, RCBO units provide superior protection, while dual RCD units offer a cost-effective solution for medium-sized homes.

Looking to buy your Fusebox Consumer Unit? Find the full range right here!
