The Ultimate Guide to Fusebox Consumer Units

Leave a comment
Consumer Units
18th Edition · Consumer Unit · FuseBox
Posted by: Electrical 4 Less AvatarElectrical 4 Less
Fusebox Consumer Unit

Fusebox Consumer Unit Range

When it comes to safeguarding your home or business’s electrical systems, selecting the right consumer unit is paramount. Fusebox, a leading brand in the electrical industry, specializes in producing high-quality consumer units designed to ensure the safe distribution and control of electricity in residential, commercial, and industrial settings. In this comprehensive guide, we delve into the various types of Fusebox consumer units, highlighting their unique features, specifications, and the benefits they offer. From main switch consumer units to products equipped with surge protection, dual tariff options, dual RCD models, EV charger cu’s, and the soon-to-be-released Three Phase TPN range, Fusebox covers all your electrical installation needs.

Why Choose a Fusebox Consumer Unit?

Fusebox consumer units are engineered to provide unparalleled safety, reliability, and efficiency. These units are critical components in any electrical installation, playing a key role in controlling and distributing electrical power throughout a building. With an emphasis on quality and innovation, Fuse box has earned a reputation for producing consumer units that not only meet but exceed industry standards. Whether you’re installing a new system or upgrading an existing one, Fuse box offers a range of consumer units tailored to meet diverse requirements, ensuring that your electrical installations are both safe and future-proof.

Fusebox Consumer Unit Options: A Closer Look

RCBO Consumer Units

At the heart of any electrical installation is the main switch consumer unit. This type of consumer unit serves as the central control point for your entire electrical system, allowing you to isolate the power supply when necessary. Fusebox offers a variety of main switch consumer units, each designed to accommodate different installation needs. These units are known for their robust construction and reliable performance, making them a popular choice for both residential and commercial applications.

Key Models:

  • Fusebox F2004M: 4 Way RCBO Consumer Unit – Height: 259mm, Width: 156mm, Depth: 113mm
  • Fusebox F2007M: 7 Way Consumer Unit – Height: 259mm, Width: 234mm, Depth: 113mm
  • Fusebox F2011M: 11 Way RCBO Consumer Unit – Height: 259mm, Width: 306mm, Depth: 113mm
  • Fusebox F2015M: 15 Way Consumer Unit – Height: 259mm, Width: 378mm, Depth: 113mm
  • Fusebox F2021M: 21 Way RCBO Consumer Unit – Height: 259mm, Width: 486mm, Depth: 113mm
  • Fusebox F2022M: 22 Way Consumer Unit – Height: 512mm, Width: 306mm, Depth: 113mm
  • Fusebox F2030M: 30 Way RCBO Consumer Unit – Height: 512mm, Width: 378mm, Depth: 113mm
  • Fusebox F2045M: 45 Way Consumer Unit – Height: 762mm, Width: 378mm, Depth: 113mm

These models cater to a wide range of installation sizes, from small residential projects to larger commercial systems. The versatility of these units ensures they can be tailored to meet specific requirements, offering both safety and convenience.

RCBO Consumer Units with Surge Protection Devices (SPD)

In today’s digital age, protecting your electrical systems from power surges and voltage spikes is more critical than ever. Fusebox’s rcbo consumer units with integrated Surge Protection Devices (SPD) offer an added layer of security. These units are specifically designed to shield your sensitive electronic equipment and appliances from potential damage caused by power surges, which can occur due to lightning strikes or fluctuations in the power grid.

Key Models:

  • Fusebox F2006MX: 6 Way Consumer Unit With SPD – Height: 259mm, Width: 234mm, Depth: 113mm
  • Fusebox F2010MX: 10 Way Consumer Unit With SPD – Height: 259mm, Width: 306mm, Depth: 113mm
  • Fusebox F2014MX: 14 Way Consumer Unit With SPD – Height: 259mm, Width: 372mm, Depth: 113mm
  • Fusebox F2020MX: 20 Way Consumer Unit With SPD – Height: 259mm, Width: 486mm, Depth: 113mm
  • Fusebox F2021MX: 21 Way Consumer Unit With SPD – Height: 512mm, Width: 306mm, Depth: 113mm
  • Fusebox F2029MX: 29 Way Consumer Unit With SPD – Height: 512mm, Width: 378mm, Depth: 113mm
  • Fusebox F2044MX: 44 Way Consumer Unit With SPD – Height: 762mm, Width: 378mm, Depth: 113mm

These SPD-equipped units provide peace of mind by ensuring that your electrical system is protected against unexpected surges, which can potentially cause costly damage or even pose a safety hazard.

Fusebox Consumer Units with SPD

Dual Tariff Consumer Units

Dual tariff consumer units from Fuse box are specifically engineered to handle installations requiring separate metering and control for different electricity tariffs. These units are ideal for systems that operate on time-of-use rates, such as those utilizing economy 7 or 10 setups, or for heating systems and storage heaters. By segregating power supply based on different tariffs, these consumer units allow for efficient energy management and cost savings.

Key Models:

  • Fusebox F2014DT: 14 Way Dual Tariff CU – Height: 259mm, Width: 372mm, Depth: 113mm
  • Fusebox F2020MDT: 20 Way Dual Tariff CU – Height: 508mm, Width: 378mm, Depth: 113mm
  • Fusebox F2030MDT: 30 Way Dual Tariff CU – Height: 512mm, Width: 378mm, Depth: 113mm

These dual tariff units are perfect for properties that need to optimize energy usage across different times of the day, providing both flexibility and efficiency in energy management.

Dual RCD Consumer Units

Dual RCD (Residual Current Device) consumer units are a hallmark of safety in electrical installations. These units feature two independent RCDs, which divide the electrical circuits into separate protection zones. In the event of a fault, only the affected circuit will be disconnected, ensuring that power remains available to the rest of the installation. Fuse Box dual RCD CU’s are designed to minimize the risk of complete power loss while enhancing safety.

Key Features:

  • Enhanced protection by segregating circuits.
  • Increased reliability and reduced downtime in the event of a fault.
  • Ideal for residential and commercial installations.

Dual RCD CU’s from Fusebox are an excellent choice for those who prioritize safety and efficiency in their electrical systems.

EV Charger Consumer Units

With the growing adoption of electric vehicles (EVs), the demand for specialized EV charger consumer units has skyrocketed. Fusebox has responded by developing consumer units specifically designed for EV charging applications. These units integrate circuit protection with the necessary components to safely and efficiently manage the charging of electric vehicles, making them an essential addition to any home or business that supports EV charging.

Key Models:

  • Fusebox EV32A: 32A EV Charger Supply Unit – Height: 261mm, Width: 152mm, Depth: 93mm
  • Fusebox EV32AX: 32A EV Charger Supply Unit With SPD – Height: 261mm, Width: 162mm, Depth: 93mm
  • Fusebox EV32B: 32A EV Charger Supply Unit With RCD – Height: 261mm, Width: 162mm, Depth: 93mm
  • Fusebox EV40A: 40A EV Charger Supply Unit – Height: 261mm, Width: 162mm, Depth: 93mm
  • Fusebox EV40AX: 40A EV Charger Supply Unit – Height: 261mm, Width: 162mm, Depth: 93mm
  • Fusebox EV40B: 40A EV Charger Supply Unit – Height: 261mm, Width: 162mm, Depth: 93mm

These units are essential for anyone looking to install an EV charging station at their property, ensuring that the charging process is both safe and efficient.

Understanding Nuisance Tripping and Its Solutions

One of the common issues faced by users of consumer units is nuisance tripping, where circuits trip unnecessarily, causing inconvenience and disruption. This can be particularly problematic in homes with sensitive electronic equipment or in installations where multiple appliances are running simultaneously.

Fusebox consumer units are designed to minimize the risk of nuisance tripping by incorporating high-quality components that ensure stable and reliable performance. Additionally, using RCBOs (Residual Current Breaker with Overcurrent Protection) in Fusebox consumer units can help prevent nuisance tripping by providing individual protection for each circuit, rather than relying on a single RCD to protect multiple circuits. This not only enhances safety but also reduces the likelihood of unnecessary disruptions.

The Role of Bidirectional RCBOs in Fusebox Consumer Units

Bidirectional RCBOs are a relatively new innovation in the world of consumer units, offering the ability to monitor and protect against electrical faults in both directions of current flow. This is particularly useful in installations with renewable energy sources, such as solar panels, where current can flow both into and out of the grid.

Fusebox’s bidirectional RCBOs are designed to integrate seamlessly into their consumer units, providing enhanced protection and ensuring that all circuits are safely monitored, regardless of the direction of current flow. This makes them an ideal choice for modern homes and businesses looking to incorporate renewable energy into their electrical systems.

Common Consumer Unit Accessories

To further enhance the functionality and safety of Fusebox consumer units, a range of accessories is available:

  • Flexi Tails: Flexible cables that connect the consumer unit to the main electrical supply, ensuring a secure and reliable connection.
  • Grommet Strips: These protect cables as they enter the consumer unit, preventing damage and ensuring compliance with safety regulations.
  • Cable Glands: Secure cables as they enter the consumer unit, providing strain relief and protecting against wear and tear.
  • Blanks: Used to cover unused slots in the consumer unit, maintaining safety and preventing accidental contact with live parts.
  • Rear Entry Grommets: Allow cables to enter the consumer unit from the rear, providing a neat and tidy installation.
  • Henley Blocks and Earth Blocks: These provide a convenient connection point for multiple cables, ensuring a secure and organized installation.
  • Bell Transformers: Used to step down voltage for doorbells and other low-voltage devices.
  • DIN Rail Timers and Single Phase Energy Meters: Additional components that can be installed within the CU for energy monitoring.

Why Fusebox Consumer Units are the Top Choice

Fusebox consumer units offer a comprehensive solution for all your electrical distribution needs. With a wide range of options, from basic main switch units to advanced models with surge protection and dual RCDs. Fusebox ensures that your installation is safe, reliable, and future-proof. The introduction of new technologies, such as bidirectional RCBOs and the TPN range, demonstrates Fusebox’s commitment to innovation and quality.

By choosing Fusebox, you’re investing in a product that not only meets current electrical safety standards but is also designed to accommodate future advancements in energy efficiency. Whether you’re a homeowner or an electrical contractor – Fusebox consumer units provide the reliability & safety you need to ensure the smooth operation of your electrical systems.

Find the full Fusebox range here!
